SO-SFP-10GE-ZR-Dxxxx & -Dxxxx-I SFP+, 10G Multirate, DWDM 100GHz, DDM, 23dB, 80km, D920-D960 (41ch)

The SO-SFP-10GE-ZR-Dxxxx is a versatile DWDM transceiver supporting a wide range of traffic formats ranging from 600 Mbps to 11.3 Gbps. The transceiver is provided in 40 channel versions at the 100GHz DWDM grid as specified in the ITU-T 694.1 standard. The optical performance is in accordance with the industry ZR/ZW-standard, providing a bridgeable distance (without dispersion compensation) of up to 80km for 10GbE-LAN (10GBASE-ZR) and 10GbE-WAN (10GBASE-ZW) services. The transceiver is available in two temperature range options, one being the Industrial temperature range (I-temp): -40°C to 85°C (-40°F to 185°F). This transceiver provides digital diagnostic functions via a 2-wire serial interface as defined by the SFF-8472 specification. The transceiver module is compliant to RoHS-6/6
